Description
POC – MAKING INSTALLATIONS A LOT SIMPLER!
Power over Coaxial (PoC) basically means that power for the camera is supplied by the DVR via coaxial video;cable (RG59 or similar), this removes the requirement for separate cables and power supplies which would;otherwise be needed to power your cameras. For installers this means a much more time and cost efficient
installation.
PoC can be used on cable runs up to 200 metres and is available in 4,8 and 16 channel DVRs (models ending;/P), a full complement of TVI PoC cameras are also available (models ending E) which together offer a cost;effective and time saving solution to your TVI installations.
PLEASE NOTE: All PoC cameras can also work on non PoC recorders
1. All PoC capable TVI cameras can be powered locally via a separate power supply allowing them to be used on a none PoC TVI DVR
2. All none PoC TVI cameras can work on a PoC capable TVI DVR as the camera is powered via a separate power supply and PoC will
only transmit when requested to by a compatible camera
3. PoC transmission has generally been used through RG59 coaxial or similar cable, however with the release of our DTV-BALUN/LEAD/HD/POC it can now also be used through CAT5 offering even greater flexibility of install.
- 5MP high performance CMOS
- Adopts HD-TVI technology
- 2.8mm fixed lens
- True day/night
- OSD menu
- Smart IR
- EXIR technology
- Up to 40m IR distance
- Up the Coax telemetry
- Digital wide dynamic range
- PoC.af
- 12V DC
